ISO 5660 Cone Calorimeter ASTM E 1354 Building Materials Heat Release
Cone Calorimeter Product Introduction:
ISO 5660 Flammability Analyzer Cone Calorimeter for Laboratory measures heat release rate(H.R.R), smoke release,ignition time, oxygen consumption, carbon monoxide, and carbon dioxide generation and mass loss rate when a specimen is exposed to a resource of the conical heater.
ISO 5660 Flammability Analyzer Cone Calorimeter for Laboratory is based on the theory that pure combustion calories are in proportion to a necessary amount of oxygen for combustion and 13.1 MJ/kg is generated whenever oxygen 1kg is consumed, and heat emission, ignition time, oxygen consumption, CO and CO2 generation, and flow of ignited gases as generated from test materials are measured.
Cone Calorimeter Standards:
• ISO 5660: Tests for reaction to fire - heat release rate, smoke generation rate and mass loss rate
• ASTM E 1354: Standard test method for heat and visible smoke release rate of materials
• BS 476 Pt.15: Testing of building materials and building structures: – Methods for testing the heat release rate of products
• GB/T 16172-2007 Test method for heat release rate of building materials
• NFPA 264
Cone Calorimeter Specification:
| Product name | ISO 5660 HRR Cone Calorimeter |
| Heater power | 5000W (0-100kW/m² PID temperature control) |
| Sample size | ≤100×100×50mm |
| Gas analysis type | Magnetic oxygen (O₂) + NDIR (CO/CO₂) |
| Smoke detection system | Laser photoelectric method (main/auxiliary dual detector) |
| Data output | HRR, total smoke production, CO/CO₂ yield, mass loss rate, etc. |
| Cooling system | Portable water cooling, no external water source required |
Cone Calorimeter Basic parameters:
1. Test parameters: heat release rate, effective calorific value, smoke analysis, flammability, flame/smoke level, etc.
2. Heater power: 50kW.
3. Sample size: 100mm x 100mm x (0.5-100)mm.
4. Flue gas analysis: CO, CO2, NOx, SOx, etc.
5. Control mode: PLC digital control.
Cone Calorimeter Precautions during operation:
1. Operate strictly in accordance with the instruction manual to ensure safety.
2. Before testing, sample pretreatment, cutting and sample chamber cleaning should be carried out.
3. Wear protective clothing, gloves, goggles and other personal protective equipment when using.
4. During the measurement process, the status and data output of the instrument should be checked regularly.
Cone Calorimeter Daily care:
1. Clean and maintain the instrument frequently to ensure the accuracy and service life of the instrument.
2. Frequently replace consumables such as gas cylinders and filters to ensure test accuracy.
3. After use, the instrument should be disassembled and cleaned, and stored in a dry and ventilated place.
Cone Calorimeter Test data :
1. Heat Flux, Unit: kW/m2
2. Exhaust duct flow rate, Unit: l/s
3. C factor, Unit:1/kg · m · K
4. Ignition time and Extinguishment time, Unit:s
5. Total oxygen consumption, Unit: g
6. Total Smoke Release, Unit: m/m2
7. Mass loss and Mass loss rate, Unit: g, g/s
8. Heat release rate, Unit: MJ/kg, kw/m2
9. Effective heat of combustion, Unit: MJ/kg
10. Carbon monoxide yield, Unit: kg/kg
11. Carbon dioxide yield, Unit: kg/kg
