ISO 4589-2 ASTM D 2863 NES 714 Intelligent LOI Limited Oxygen Index Tester
Limited Oxygen Index Tester Introduction:
The Limited Oxygen Index Tester is designed to determine the minimum oxygen concentration required to sustain combustion of materials under controlled conditions. Utilizing an imported paramagnetic oxygen sensor and high-precision mass flow controllers, this analyzer ensures accurate and reliable results for homogeneous solids, laminated materials, foams, films, and textiles. It is ideal for laboratories and industries focused on fire safety evaluation, compliant with ISO 4589-2, GB/T 2406-2009, and other international standards.
Limited Oxygen Index Tester standard:
* ASTM D 2863
* ISO 4589-2
* NES 714
Limited Oxygen Index Tester Technical Specification:
| Oxygen concentration measurement range | 0-100% |
| Resolution | 0.1% |
| Accuracy | +/-0.2% |
| Response time | <300ms |
| Oxygen stability time | <30s |
| Oxygen concentration sensor | England Servomex Paramagnetic type oxygen sensor, accuracy: +/-0.1% |
| Gas displacement | 50L/S |
| Size | 600(W)*310(D)*545(H)mm |
| Workbench size | 1500(W)*600(D)*800(H)mm |
| Weight | 30kg |
| Power supply | AC 220V, 50/60Hz, 5A |
Limited Oxygen Index Tester Features:
1. Imported needle valve, precise control of gas flow;
2. Imported gas flow meter, precise display of gas flow
3. Imported brand pressure regulating valve and pressure gauge;
4. Equipped with high temperature resistant quartz glass cylinder
5. Equipped with supported and unsupported sample clamps
6. Portable igniter is easy to operate, and high-precision needle valve controls the igniter flame height;
7. Patented gas mixing chamber ensures more accurate oxygen concentration measurement and more stable combustion.
8. Ignitor inner diameter: 2mm ± 1 mm
9. Oxygen concentration measurement range: 0-100%
10. Flow meter range: 1.0~10.0L/min
11. Response time: <1s
12. Glass cylinder height 500mm;
